BLUEnet Node

The SALTO wireless BLUEnet Node is a bridge the gateway and the escutcheons or cylinders, where the distance to the escutcheon or where the number of escutcheons that must be linked to the gateway exceeds what is possible with a single gateway.

It also permits to combine in a same property wireless

Get in Touch with us to purchase

Scroll down for more information ▼

MAIN FEATURES

  • Compatible with SALTO BLUEnet wireless network.
  • Wireless radio frequency based on Bluetooth Low Energy.
  • AES 128bits encryption.
  • Connection to the RFnet Gateway or BLUEnet Gateway by BUS 485.
  • Powered by the Gateway.
  • Can manage up to 16 wireless locks.
  • Firmware update via software through Ethernet connection.

TECHNICAL CHARACTERISTICS:

  • Operation conditions
    • Temperature: Min -20º – Max 70º
    • Humidity: Min 35% – Max 85%
  • Cable requirements:
    • Node Connection (AB): Generic twisted pair wire
    • Node Connection (Vdd): 24 AWG
  • SALTO BLUEnet characteristics (if internal node installed):
    • Frequency Range: 2400-2483,5 Mhz
    • RF Standard: Bluetooth Low Energy
    • Indoor Radio Range: 5m/10m
    • Max output power: 8dBm
  • Auxiliary Power Supply:
    • Input voltage: 7V (Min.) – 28V (max)
    • Current consumption: 45mA

PLATFORMS

  • SALTO Virtual Network (SVN) data-on-card
    • SALTO ProAccess SPACE software compatible

CERTIFICATIONS



Downloads

Datasheet
