DBolt Touch

The DBolt Touch is a smart deadbolt that simply replaces an existing mechanical deadbolt. The DBolt Touch is an easy-to-install smart lock for the unit door that adds smart features to your lock and maintains the design integrity of your home.

Get in Touch with us to purchase

Scroll down for more information ▼

The DBolt Touch is a smart deadbolt that simply replaces an existing mechanical deadbolt. The DBolt Touch is an easy-to-install smart lock for the unit door that adds smart features to your lock and maintains the design integrity of your home.

MAIN FEATURES

  • Salto SVN and Salto BLUEnet Wireless network capable.
  • Built in a high-quality zinc alloy body.
  • Specially designed to retrofit existing mechanical deadbolts.
  • High-quality intuitive LED display offering multiple unlocking access methods for users.
    • User pass code (PIN)
    • Physical Credential – SVN
    • Digital key – NFC / Bluetooth LE
    • Apple Wallet*
  • Dual color green/red to indicate authorisation.
  • The Salto DBolt Touch meets the highest standards set by the security industry. Rated AAA according to A156.40 (American National Standard for Residential Deadbolts).
  • Deadbolt included
    • Back sets:
      • 2-3/8″ (60mm) or
      • 2-3/4″ (70mm)
    • Face plates*:
      • 1-1/8″ (28,5mm) SQUARE CORNER or
      • 1″ (25,4mm) SQUARE CORNER or
      • 1″ + R1/4″ (25,4mm + R6,4mm ) RADIUS ROUND CORNER

    * Please consult Salto for combination availabilities.

    TECHNICAL CHARACTERISTICS:

    • Outside housing dimensions: 6-5/16″ (160mm) x 2-11/16″ (68mm) x 1-13/16″ (46mm)
    • Inside housing dimensions: 5-13/16″ (148mm) x 2-13/16″ (72mm) x 2-5/64″ (52,7mm)
    • Door thickness: 1-3/8″ (35mm) – 3-11/32 (85mm)”
    • Power source: 3 AA batteries (LR6 1,5V)

    PLATFORMS

    • Salto Space
      • On-premise Network
    • Salto KS
      • Cloud Application
    • Salto Homelok
      • Cloud Application

    Credential Technologies

    • Salto Justin Mobile Credentials: Bluetooth Digital Key and Near Field Communication (NFC) capability.
    • NXP MIFARE®: MIFARE® DESFire® EV1/EV2/ EV3, MIFARE® Plus, MIFARE® Ultralight C, MIFARE® Classic.

    CORE TECHNOLOGIES

    • SVN Data-on-Card
    • BLUEnet Wireless
    • JustIN Mobile
    • Apple Wallet*

    *Not available in all platforms.

    CERTIFICATIONS



    FINISHES

Downloads

Datasheet
