Glass XS Reader

The Glass XS Reader transforms spaces into sophisticated and enriched environments. With its unique design and cutting-edge technology, it offers users and systems operators an optimal access control experience that is second to none. The Glass XS Reader delivers a complete security solution for situations where control must be boosted by online and real-time access

Get in Touch with us to purchase

Scroll down for more information ▼

MAIN FEATURES

  • Stylish design and tempered glass.Extra-flat minimalist design – just 4 mm thick.
  • Modern aesthetic design with clear green/red and blue LED color optical signal.
  • Flush mounting in wall with universal mechanism box.
  • Easy to install. The sleek design form factor is easy to flush mount and install with standard electrical boxes.
  • Standardized RFID credentials, including Bluetooth, NFC, and virtual network capable, through Salto Virtual Network (SVN) data-on-card technology.
  • All communication the carrier and the wall reader is encrypted and secure.
  • Acoustic and optical signaling, dual color green/red to indicate access authorisation.
  • Blue light indicates that the user key update is in progress through SVN technology.
  • Reader is housed in a two-piece, weatherproof secure electronics potted enclosure.

TECHNICAL CHARACTERISTICS:

  • Mobile and physical credential technologies compatible, including Bluetooth LE, NFC and RFID.
  • To be used in combination with controllers (CU42xxx) or BLUEnet Door Controller (CUCxxx).
  • Connection to the door controller: 4 wires.
  • Simplify network infrastructure with the latest advancements in BLUEnet wireless technology capabilities and connectivity for cloud access control and mobile applications.
  • Reading distance from 35 to 50mm depending on the RFID technology.
  • Maximum distance the door controller and the wall reader 400m using a twisted pair cable.

PLATFORMS

  • SALTO Space
    • SVN Data-on-card
    • Wireless (SALTO BLUEnet)
    • SVN-FLEX
  • SALTO KS
    • Wireless (SALTO BLUEnet)
  • SALTO Homelok
    • Wireless (SALTO BLUEnet)
    • SVN-FLEX

CREDENTIAL TECHNOLOGIES

  • SALTO Justin Mobile Credentials: Mobile Key Bluetooth and Near Field Communication (NFC) capability.
  • NXP MIFARE®: MIFARE® DESFire® EV1/EV2/ EV3, MIFARE® Plus, MIFARE® Ultralight C, MIFARE® Classic.

CERTIFICATIONS



READER COLOUR

Downloads

Datasheet
